Integra DTR-6.4 - Page 96

Transistors
Q2901 2215960 or KRC102M or
2213290 DTC114ES
Q2902 2212855 or 2SB1068-U or
Q2908,Q2909 2212853 2SB1068-K
Q2904,Q2905 2215960 or KRC102M or
Q2906,Q2907 2213290 DTC114ES
Capacitors
C2902 394642217 or CE04W16V-220M(VR) or
394742217 CE04W16V220M(SC),Elect. <D>
C2903 394621017 CE04W6.3V-100M(VR),Elect.
C2904 374722234 ECQ-B50V-223J,Plastic
C2905 394644707 or CE04W16V-47M(VR) or
394744707 CE04W16V47M(SC),Elect.
Thermistors
R2904,R2905 4000195 RXE030
Sockets
P105B,P107B 25051241 NSCT-20P1031
Plugs
P2001A 25055703 NPLG-7P659 <D>
P207A 25055706 NPLG-10P662
P208A 25055805 NPLG-16P761
P2201A 25055701 NPLG-5P657
P2202A 25055703 NPLG-7P659
P2210A 25055703 NPLG-7P659
P2212A 25055704 NPLG-8P660
PRE-OUTPUT TERMINAL PC BOARD (NAAF-7983-1H/1I)
CIRCUIT NO. PART NO. DESCRIPTION
Capacitors
C6880~C6882 374721024 ECQ-B50V-102J,Plastic
C6890~C6899 374721024 ECQ-B50V-102J,Plastic
Terminals
P6810 25045424 NPJ-2PDBL249
P6811 25045734 NPJ-6PDWRLEGP522
P6812 25045735 NPJ-2PDNT523
Socket
JL5801A 25051096 NSCT-12P883
DRIVER CIRCUIT PC BOARD
(
NAAF-7984-1H/1I
)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5000~Q5002 2211733 or * 2SC1845-E or
2211732 * 2SC1845-F
Q5003~Q5005 2215896, * KTC3200-BL,
2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
2211733 * 2SC1845-E
Q5010~Q5012 2211733 or * 2SC1845-E or
2211732 * 2SC1845-F
Q5013~Q5015 2215896, * KTC3200-BL,
2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
