DTR-8.3
SPECIFICATIONS
AMPLIFIER SECTION
Continuous average power output (FTC)
All channels: 110 W per channel min. RMS at 8
, 2 channels driven from 20 Hz to
20 kHz with no more than 0.08%
total harmonic distortion.
145 W min. RMS at 6 , 2 channels
driven from 1 kHz with no more
than 0.1% total harmonic
distortion.
Continuous power output (DIN) 150 W at 6
Maximum power output (EIAJ) 180 W at 6
Dynamic power output (stereo) 2 280 W at 3
2 220 W at 4
2 140 W at 8
Total Harmonic Distortion: 0.08% at rated power
0.08% at 1 W output
IM Distortion: 0.08% at rated power
0.08% at 1 W output
Damping factor: 60 at 8
Input sensitivity and impedance
PHONO: 2.5 mV, 50 k
LINE (CD, TAPE, DVD,
VIDEO 1-5): 200 mV, 50 k
MULTICHANNEL INPUT
(FRONT L/C/R, SURROUND
L/R, SURROUND BACK L/R): 200 mV, 50 k
(SUBWOOFER): 36 mV, 50 k
COAXIAL 1, 2, 3 (DIGITAL): 0.5 Vp-p, 75
DVD, VIDEO 1, 2, 3, 4, 5: 1 Vp-p, 75
1 Vp-p, 75 (Y)
0.28 Vp-p, 75 (C)
COMPONENT VIDEO 1, 2: 1 Vp-p, 75 (Y)
0.7 Vp-p, 75 (P
B, PR)
Output level and impedance
Rec out (TAPE, VIDEO 1, 2):
200 mV, 470
Pre out: 1 V, 470
ZONE 2 OUT: 100 mV, 470
VIDEO (VIDEO 1, 2, MONITOR
OUT, ZONE 2 OUT): 1 Vp-p, 75
S-VIDEO (VIDEO 1, 2,
MONITOR OUT): 1 Vp-p, 75 (Y)
0.28 p-p, 75 (C)
COMPONENT VIDEO OUT: 1 Vp-p, 75 (Y)
0.7 Vp-p, 75 (P
B, PR)
Phono overload:
120 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency response: 10 Hz to 100 kHz : +1/–3 dB
(CD in Direct mode)
RIAA deviation: 20 Hz to 20 kHz : ±0.8 dB
Tone Control
Bass: ±10 dB at 50 Hz
Treble: ±10 dB at 20,000 Hz
Signal-to-noise ratio (direct)
Phono: 80 dB (IHF A, 5 mV input)
CD/Tape: 110 dB (IHF A, 0.5 V input)
TUNER SECTION
FM
Tuning range
USA & Canadian models: 87.50–108.00 MHz (100-kHz steps)
Other models: 87.50–108.00 MHz (50-kHz steps)
Usable sensitivity
Mono: 11.2 dBf, 1.0 µV (75 IHF)
0.9 µV (75 DIN)
Stereo: 17.2 dBf, 2.0 µV (75 IHF)
23 µV (75 DIN)
50 dB quieting sensitivity
Mono: 17.2 dBf, 2.0 µV (75 )
Stereo: 37.2 dBf, 20 µV (75 )
Capture ratio: 2.0 dB
IF rejection ratio: 90 dB
Signal-to-noise ratio
Mono: 76 dB
Stereo: 70 dB
Alternate channel attenuation: 55 dB
Selectivity: 50 dB (DIN)
AM suppression ratio: 50 dB
Total harmonic distortion
Mono: 0.2%
Stereo: 0.3%
Frequency response: 30 Hz–15 kHz, ±1.0 dB
Stereo separation: 45 dB at 1 kHz
30 dB at 100 Hz –10 kHz
AM
Tuning range
USA & Canadian models: 530 to 1,710kHz (10kHz steps)
522 to 1,611 kHz (9-kHz steps)
Australian models:
Usable sensitivity: 30 µV
Image rejection ratio: 40 dB
IF rejection ratio: 40 dB
Signal-to-noise ratio: 40 dB
Total harmonic distortion: 0.7%
GENERAL
Power supply
USA & Canadian models: AC 120 V, 60 Hz
Australian models: AC 230 –240 V, 50 Hz
Power consumption
USA & Canadian models: 8.4 A
Australian models: 670 W
Dimensions (W H D): 435 175 460 mm
17-1/8" 6-7/8" 18-1/8"
Weight
18.2 kg (40.1 lbs)
Specifications and features are subject to change without notice.
REMOTE CONTROLLER
Model:
USA & Canadian
models: USR-5
Australian models: USR-5RF
Hardware: High-resolution (320 240) liquid crystal
display (LCD) with contrast control
Large touchscreen
Seven programmable direct-access buttons
Backlighting for LCD and direct-access
buttons
Infrared sending and learning eyes
3-wire (RS232) serial port connector
Software: Dynamic, animated interface
Editable macros (up to 255 commands per
macro)
Total number of devices and macros limited
only by memory
Database with RC codes to operate different
brands
Infrared (IR): Operating distance of 33 feet(10 meters)
Learning frequency up to 56 kHz
Learning distance 2 inch (5 cm) up to 1 foot
(30 cm)
Memory: 2 MB non-volatile flash memory (retains
commands when batteries are not present)
512 K SRAM
Batteries: 4 AA 1.5 V batteries, or one 4.8V rechargeable
battery pack (USA and Canadian model)
Battery life: Approximately 6 months with typical use
Power management: Power on by tapping the touchscreen, power
off automatically management
Dimensions: 6.0 inch 3.7 inch 1.7 inch
(153.6 94.1 43.7 mm)
Operating temperature:32 ˚F to 122 ˚F (0 ˚C to 50 ˚C)
(USA & Canadian models only)
Radio
frequency (RF): Operating distance of approximately 66 feet
(20 meters) depending on the surrounding
conditions
Band: 418 MHz
Bandwidth: +/–100 kHz
16 Extender ID’s and 4 Channels
Accessories
(Not included): Remote controller recharge package BCC-5
RF Receiver RFR-5
Database information:
Designed by UEI Technology
Licensed under U.S. Patent 5,689,353
Portions UEI 1999
