Integra DTR-8.3 Service Manual

CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<A>: Australian model only
REF. NO. PART NO. DESCRIPTION
1 27111242C Front bracket
2 27191153B Holder, jack
3 838430088 3TTB+8B(BC), Self-tapping screw
4 838130088 3TTB+8B, Self-tapping screw
6 28141447 Cushion
7 28191939 Clear plate
8 28133387 Back plate
9 28198905 Facet
10 82143010 3P+10FN(BC), Pan head screw
12 28198933 Facet 5
13 28198936 Facet 6
14 28159047 Decorative frame
16 28135278 Badge
18 28148526 Door
19 27230047 Push latch
20 27191179 Holder R
21 27191178 Holder L
22 28180160 Hinge L
23 28180161 Hinge R
24 27301947 Damper
25 27301946 Gear
27 831430088 3TTW+8B(BC), Self-tapping screw
28 801433 3SMS8W.SW+14B(BC), Special screw
29 838430088 3TTB+8B(BC), Self-tapping screw
29 838120088 2TTB+8B, Self-tapping screw
30 28325913 Knob, volume
31 28325756 Knob, standby
33 27100408-1A Chassis
34 27130870A Bracket, power transformer
35 27190965 Holder
36 27190693A KGLS-6RF, Holder
37 27190266 KGLS-12RF, Holder
38 27190164 KGLS-14S, Holder
39 830440089 4TTC+8C(BC), Self-tapping screw
40 28141511 t1.0*5*5, Cushion
41 28141484 Cushion
42 27191112 KGPS-6RF, Holder
43 27141797 Retainer, fan
44 27150470 Shield plate, fan
45 838450108 5TTB+10B(BC), Self-tapping screw
46 880016 P3035B, Plastic rivet
47 27150471 Shield plate
49 27150474 Shield plate, wire
52 27160489A Heat sink
53 801606 3SMH10W.SW+15B(CU), Special screw
54 27141681 Retainer, PC board
55 27141798 Retainer R, heat sink
56 27141799 Retainer L, heat sink
57 27130869 Bracket, heat sink
58 27130745 Bracket
59 27255004 CS-1U, Clip
61 838430107 3TTB+10S(BC), Self-tapping screw
62 28184817-1 Top cover
63 29363226 Label, display
64 29362772 Label, cover
65 838430088 3TTB+8B(BC), Self-tapping screw
66 838440089 4TTB+8C(BC), Self-tapping screw
67 27175319B Leg
68 28141494 Cushion
69 831430088 3TTW+8B(BC), Self-tapping screw
REF. NO. PART NO. DESCRIPTION
70 27123034-1 Rear panel <D>
27123042-1 Rear panel <A>
71 838430088 3TTB+8B(BC), Self-tapping screw
72 87643010 W3*10F(BC), Flat washer
73 838930088 3TTB+8B(UN), Self-tapping screw
74 838440089 4TTB+8C(BC), Self-tapping screw
75 838430068 3TTB+6B(BC), Self-tapping screw
81 27212450 Front panel
82 27262683 Plate, door
83 27190470 KGLS-18S, Holder
86 260208 Binder
87 260258 Binder
91 27225149 Shield case
92 27150485 Shield plate
95 29362609 Label, power transformer
97 223025 AC262, Isolated sheet
98 29363264 Label MAC
99 27141827 Retainer A
E821 24502310 D09T-24PG10(EX), Fan
F6901,F6902 252100 ! 10A-EAK, Fuse <A>
F6901,F6902 252196 ! 12A-UL/T-314, Fuse <D>
F901 252196 ! 12A-UL/T-314, Fuse <D>
F902 252078, ! 5A-SE-EAK,
252244 or ! 5A-SE-TL250V or
252278 ! 5A-SE-TL250V, Fuse <A>
F903 252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <A>
F9501,F9502 252160 or ! 2.5A-UL/T-237 or
252254 ! 2.5A-T/UL-ST2, Fuse <D>
252075, ! 2.5A-SE-EAK,
252241 or ! 2.5A-SE-TL250V or
252275 ! 2.5A-SE-TL250V, Fuse <A>
F9501A 29363313 T2.5AL1.6AL250V, Label, fuse <A>
F9503,F9504 252158 or ! 1.6A-UL/T-237 or
252252 ! 1.6A-T/UL-ST2, Fuse <D>
252073, ! 1.6A-SE-EAK,
252239 or ! 1.6A-SE-TL250V or
252273 ! 1.6A-SE-TL250V, Fuse <A>
P1010 2047151012 NCFC7-151012, Flexible cable
P2901 2047191012 NCFC7-191012, Flexible cable
P6009 27141825 Retainer, bus
P602 2009990753UL NSAS-8P1059, Socket
P603 204406027 NCFC4-062512, Flexible cable
P603C 79012 Tube FFC
P6205 27141826 Retainer, bus
P7201 2047312512 NCFC7-312512, Flexible cable
P7701 2047051012 NCFC7-051012,Flexible cable
Q6050~Q6056 2203083 or * 2SC5359-O or
2203082 * 2SC5359-R, Transistor
Q6060~Q6066 2203073 or * 2SA1987-O or
2203072 * 2SA1987-R, Transistor
Q9422A 223026 Isolated sheet
Q9422B 223032 TO-66(1), Isolated washer
T901 2301649 ! NPT-1453D, Power transformer <D>
2301650 ! NPT-1453P, Power transformer <A>
U1 1A956587-1C NADG-7687-1C, DSP circuit PC
board ass'y
U2 1A956562-2 NADG-7662-2,Net-tune circuit PC
board ass'y
DTR-8.3
EXPLODED VIEW-PARTS LIST
