Integra DTR-8.3 Service Manual

NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note: <D>: 120V model only <A>: Australian model only
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
CIRCUIT NO. PART NO. DESCRIPTION
Capacitors
C100~C103 356744709R2 47uF,16V, Elect., chip
C108,C110 356724709R2 47uF,6.3V, Elect., chip
C113,C114 373021524R2 1500pF+/-5%,50V,Plastic
C116,C119 356723319R2 330uF,6.3V, Elect., chip
C141,C148 356724709R2 47uF,6.3V, Elect., chip
C150 356741009R2 10uF,16V, Elect., chip
C152 356724709R2 47uF,6.3V, Elect., chip
C157 3567A1019R2 100uF,4V, Elect., chip
C159 356784799R2 0.47uF,50V, Elect., chip
C167,C170 356724709R2 47uF,6.3V, Elect., chip
C172 356724709R2 47uF,6.3V, Elect., chip
C176 356744709R2 47uF,16V, Elect., chip
C177,C178 3567A1019R2 100uF,4V, Elect., chip
C7000 3000078 or DX-5R5L104 or
3000121 SCDA5R5104V, Super
C7002,C7003 356721019R2 100uF,6.3V, Elect., chip
C7004 356780109R2 1uF,50V, Elect., chip
C7005 356721019R2 100uF,6.3V, Elect., chip
C719,C720 3567A1019R2 100uF,4V, Elect., chip
C764~C766 3567A1019R2 100uF,4V, Elect., chip
C802,C807 356723319R2 330uF,6.3V, Elect., chip
C819,C820 373024724R2 4700pF+/-5%,50V,Plastic
C823,C824 373024724R2 4700pF+/-5%,50V,Plastic
C826 373043334R2 0.033uF+/-5%,16V,Plastic
C827~C830 373026814R2 680pF+/-5%,50V,Plastic
C831~C834 373023314R2 330pF+/-5%,50V,Plastic
C835~C838 373026814R2 680pF+/-5%,50V,Plastic
C839,C840 373023314R2 330pF+/-5%,50V,Plastic
C847,C848 356744709R2 47uF,16V, Elect., chip
C849,C850 356741019R2 100uF,16V, Elect., chip
C851~C854 356744709R2 47uF,16V, Elect., chip
Resistors
R782 43474056004R1 RM0KJ560X04,Array
R787~R791 43474056004R1 RM0KJ560X04,Array
Terminal
P101 25045624 NPJ-3PDO431
Sockets
P603B 25052572R2 NSCT-6P2469
P7002,P7004 25051527 NSCT-16P1314
P7003,P800 25051241 NSCT-20P1031
P7701A 25052277R2 NSCT-5P2174
Plugs
P100 25055133 NPLG-3P117
P7000 25056056 NPLG-8P1006
Cushion
Q800A 28141445 (DAC)
F/C ch.driver circuit PC board (NAAF-7690-1H/1J)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5000~Q5002 2215896, * KTC3200-BL,
Q5010~Q5012 2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
2211733 * 2SC1845-E
Q5020~Q5022 2215896, KTC3200-BL,
2210755, 2SC1775A-E,
2210756 or 2SC1775A-F or
2211733 2SC1845-E
Q5030~Q5032 2215844, KTA1024-Y,
Q5040~Q5042 2211353, 2SA949-O,
2211354 or 2SA949-Y or
2215843 KTA1024-O
CIRCUIT NO. PART NO. DESCRIPTION
Capacitors
C901 3500196S ! RE275V-103M,IS
C922 394662217 220uF,35V, Elect.
Resistors
R901 4000206S or ! RD1/2SPH-3.3M or
431533355 ! RC1/2GFKUL-3.3M <D>
R924 443528204 82ohm+/-5%, 1/2W, Metal oxide
Relay
RL901 25065584 or ! NRL-1P10A-DC12-140 or
25065516 ! NRL-1P10A-DC12-097
Fuses
F901 252196 12A-UL/T-314, Fuse <D>
F902 252078, 5A-SE-EAK,
F902 or 252244 or 5A-SE-TL250V or
F902 or 252278 5A-SE-TL250V, Fuse <A>
F903 252075, 2.5A-SE-EAK,
F903 or 252241 or 2.5A-SE-TL250V or
F903 or 252275 2.5A-SE-TL250V, Fuse <A>
Fuse holders
F901A,F901B 250113 ! SN5051 <D>
F902A,F902B 25052133 ! NSCT-1P2031 <A>
F903A,F903B 25052133 ! NSCT-1P2031 <A>
AC outlet
P902 25051126 ! NSCT-4P913 <D>
P902 25052115 ! NSCT-2P2013 <A>
Sockets
JL931B 25050267 NSCT-3P95
Plug
P911 25055675 or NPLG-2P631 or
25056028 NPLG-2P0978
Fuse labels
F901C 29362325 12A/250V <D>
F902C 29361938 T5AL250V <A>
Bias selector relay PC board (NAPS-7692-1H/1J)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6901,D6902 22380260, RL1N4003,
22380032 or 1SR139-100 or
22380035 GP104003E
D6903,D6904 22380309 or D15XB60 or
22380044 RBV-1506
D6906 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Capacitors
C6903 374722234 0.022uF+/-5%,50V,Plastic
C6908,C6909 374733344 0.33uF+/-5%,100V,Plastic
C6910,C6911 374723344 0.33uF+/-5%,50V,Plastic
C6915,C6916 374733344 0.33uF+/-5%,100V,Plastic
Relays
RL6901,RL6902 25065584 or NRL-1P10A-DC12-140 or
25065516 NRL-1P10A-DC12-097
Fuses
F6901,F6902 252100 10A-EAK, Fuse <A>
252196 12A-UL/T-314, Fuse <D>
Fuse holders
F6901A,F6901B 250113 ! SN5051 <D>
F6901A,F6901B 25052133 ! NSCT-1P2031 <A>
F6902A,F6902B 250113 ! SN5051 <D>
F6902A,F6902B 25052133 ! NSCT-1P2031 <A>
Socket
JL6953B 25050268 NSCT-4P96
DTR-8.3
PRINTED CIRCUIT BOARD-PART LIST 2
