80960KB
36
Figure 30. Accesses Generated by Quad Word Read Bus Request, Misaligned Two Bytes from Quad
Word Boundary (1, 0, 0, 0 Wait States)
T
a
T
w
T
d
T
d
T
d
T
d
T
r
T
a
T
w
T
d
T
r
CLK2
CLK
LAD31:0
ALE
ADS
BE3:2
W/R
DT/R
DEN
READY
BE1:0
