RX Reconfiguration Management

• 0: No oversampling

• 1: 5× oversampling

reconfig_mgmt_write

Output 1 RX reconfiguration management Avalon-

MM interface to transceiver arbiter

reconfig_mgmt_read

Output 1

reconfig_mgmt_address

Output 12

reconfig_mgmt_writedata

Output 32

reconfig_mgmt_readdata

Input 32

reconfig_mgmt_waitrequest

Input 1

HDMI RX Core Signals

TMDS_Bit_clock_Ratio

Output 1 SCDC register interfaces

audio_de

Output 1 HDMI RX core audio interfaces

audio_data

Output 256

audio_info_ai

Output 48

audio_N

Output 20

audio_CTS

Output 20

audio_metadata

Output 165

audio_format

Output 5

aux_pkt_data

Output 72 HDMI RX core auxiliary interfaces

aux_pkt_addr

Output 6

aux_pkt_wr

Output 1

aux_data

Output 72

aux_sop

Output 1

aux_eop

Output 1

aux_valid

Output 1

aux_error

Output 1

gcp

Output 6 HDMI RX core sideband signals

info_avi

Output 112

info_vsi

Output 61

colordepth_mgmt_sync

Output 2

vid_data

Output N*48 HDMI RX core video ports

Note: N = symbols per clock

vid_vsync

Output N

vid_hsync

Output N

vid_de

Output N

mode

Output 1 HDMI RX core control and status ports

continued...

2 Intel FPGA HDMI Design Example Detailed Description
