HDMI TX Core Signals
audio_data
Input 256
audio_info_ai
Input 49
audio_N
Input 22
audio_CTS
Input 22
audio_metadata
Input 166
audio_format
Input 5
aux_ready
Output 1 HDMI TX core auxiliary interfaces
aux_data
Input 72
aux_sop
Input 1
aux_eop
Input 1
aux_valid
Input 1
gcp
Input 6 HDMI TX core sideband signals
info_avi
Input 113
info_vsi
Input 62
vid_data
Input N*48 HDMI TX core video ports
Note: N = symbols per clock
vid_vsync
Input N
vid_hsync
Input N
vid_de
Input N
I
2
C and Hot Plug Detect Signals
tx_i2c_avalon_waitrequest
Output 1 I
2
C master Avalon-MM interfaces
tx_i2c_avalon_address
Input 3
tx_i2c_avalon_writedata
Input 32
tx_i2c_avalon_readdata
Output 32
tx_i2c_avalon_chipselect
Input 1
tx_i2c_avalon_write
Input 1
tx_i2c_avalon_irq
Output 1
hdmi_tx_i2c_sda
Inout 1 HDMI TX DDC and SCDC interfaces
hdmi_tx_i2c_scl
Inout 1
hdmi_tx_hpd_n
Input 1 HDMI TX hotplug detect interfaces
tx_hpd_ack
Input 1
tx_hpd_req
Output 1
