Intel Bay Trail Series User Manual

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard

Onboard Intel
®
Bay Trail Series Processor, with low power consumption never
denies high performance

Support 2 * DDR3L 1066/1333 MHz SO-DIMM up to 16GB, support dual channel
function

Onboard RTL8111G Gigabit Ethernet LAN chip

Integrated ALC887 HD audio chip

Support full-size Mini-PCIE connector

Support m-SATA connector

Support USB 3.0 data transport demands

Integrated with 24-bit dual channel LVDS header

Support VGA display output & DVI-D display output

Support 1 * SATAII (3Gb/s) Device

Supports ACPI S3 Function

Support CPU Smart FAN

Support Thunder Protection Function

Compliance with EuP Standard

All Solid Capacitor design

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
