Intel Bay Trail Series User Manual

3

1 *24-pin main power connector

1*CPU fan connector

1*System fan connector

1 * Front panel audio header

1 * HDMI_SPDIF header

1 * COM header

1 * Front panel header

1* LVDS inverter header

1 * LVDS header
1-3 Layout Diagram
Rear IO Diagram
MIC-IN
Line-OUT
PS/2
Keyboard Port
USB 2.0 Ports
RJ-45 LAN Port
PS/2
Mouse Port
DVI-
D Port
VGA Port
USB 3.0 Port
Line-IN

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
