Intel Bay Trail Series User Manual

2
1-2 Specification
Spec Description
Design

Mini-ITX form factor ;

PCB size: 17.0 x 17.0 cm
Embedded CPU

Intel
®
Bay Trail-D/M/I series CPU
Memory Slot

2* DDR3L SO-DIMM slot for un-buffered 2* 1066/1333
MHz
DDR3L SO-DIMM expandable to 16GB

Support dual channel function
Expansion Slot

1* Full-size Mini-PCIE slot
Storage

1* SATA II 3G/s Connector

1 * M-SATA Connector
LAN Chip

Integrated with Realtek RTL8111G PCI-E Gigabit LAN
chip

Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
Audio Chip

Realtek ALC887 HD Audio Codec integrated

Audio driver and utility included
BIOS

64M DIP Flash ROM
Multi I/O
Rear Panel I/O:

1* PS/2 keyboard connector

1* PS/2 mouse connector

1 * VGA port

1 * DVI-D port

1* USB 3.0 port

2* USB 2.0/1.1 port

1* RJ-45 LAN port

1* Audio Line-in connector

1* Audio Line-out connector

1* Audio MIC connector
Internal I/O Connectors& Headers:

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
