Intel Desktop Board DG41TX Technical Product Specification
12
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Descri
ption
A Front panel audio header
B Conventional PCI bus add-in card connector
C Conventional PCI bus add-in card connector
D PCI Express x1 bus add-in card connector
E PCI Express x16 bus add-in card connector
F Piezoelectric speaker
G Back panel connectors
H Processor core power connector (2 x 2)
I Rear chassis fan header
J Battery
K LGA775 processor socket
L Intel 82G41 GMCH
M Processor fan header
N DIMM Channel A socket
O DIMM Channel B socket
P Diskette drive connector
Q Parallel ATA IDE connector
R Main power connector (2 x 12)
S Standby power LED
T Intel 82801GB I/O Controller Hub (ICH7)
U Serial ATA connectors (4)
V Front chassis fan header
W Chassis intrusion header
X BIOS Setup configuration jumper block
Y Front panel USB header
Z Front panel USB header
AA Front panel header
BB Alternate front panel power LED header
CC Serial port header
DD Intel
®
High Definition Audio Link header
EE S/PDIF header
