1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the Intel Desktop Board DG41TX.
Table 1. Feature Summary
Form Factor MicroATX (9.60 inches by 8.60 inches [243.84 millimeters by 218.44 millimeters])
Processor Support for the following:
• Intel
®
Core™2 Quad processor Q6000/Q8000/Q9000 series in an LGA775 socket
• Intel
®
Core™2 Duo processor E4000/E6000/E7000/E8000 series in an LGA775
socket
• Intel
®
Pentium
®
Dual-Core processor E2000/E5000 series in an LGA775 socket
• Intel
®
Celeron
®
processor 400/1000 series in an LGA775 socket
• Intel
®
Xeon
®
processor 3000/X3000 series in an LGA775 socket
Memory
• Two 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR3 800 MHz, DDR3 1066 MHz, or DDR3 1333 (OC) MHz DIMMs
• Support for up to 4 GB of system memory
• Support for non-ECC memory
Chipset
Intel
®
G41 Express Chipset**, consisting of:
• Intel
®
82G41 Graphics and Memory Controller Hub (GMCH)
• Intel
®
82801GB I/O Controller Hub (ICH7)
Video Integrated Graphics:
• Intel
®
Graphics Media Accelerator X4500 (Intel
®
GMA X4500) onboard graphics
subsystem with support for:
― Analog Displays (VGA)
― Digital Displays (DVI-D)
External Graphics:
• PCI Express* x16 add-in graphics card connector
• PCI Express x1 add-in card connector
• Conventional PCI* bus add-in card connectors
Audio 8-channel (5.1 +2) audio using the Realtek* ALC888VC high definition audio codec
Legacy I/O
Control
ITE IT8721F based legacy I/O controller with support for hardware management,
and PS/2*, parallel, and serial ports
continued
