Intel Desktop Board DG41TX Technical Product Specification
26
1.11 LAN Subsystem
The LAN subsystem consists of the following:
• Intel 82801GB ICH7
• Broadcom BCM57788 Gigabit Ethernet Controller for 10/100/1000 Mbits/s Ethernet
LAN connectivity
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface between ICH7 and the LAN controller
• Conventional PCI bus power management
⎯ ACPI technology support
⎯ LAN wake capabilities
• LAN subsystem software
For information about Refer to
LAN software and drivers http://downloadcenter.intel.com
1.11.1 LAN Subsystem Software
LAN software and drivers are available from Intel’s World Wide Web site.
For information about Refer to
Obtaining LAN software and drivers Section 1.2, page 14
