Table 10 lists the component-side connectors and headers identified in Figure 10.
Table 10. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 1 Descri
ption
A Front panel audio header
B Conventional PCI bus add-in card connector
C Conventional PCI bus add-in card connector
D PCI Express x1 bus add-in card connector
E PCI Express x16 bus add-in card connector
F Processor core power connector (2 x 2)
G Rear chassis fan header
H Battery
I Processor fan header
J Diskette drive connector
K Parallel ATA IDE connector
L Main power connector (2 x 12)
M Serial ATA connectors (4)
N Front chassis fan header
O Chassis intrusion header
P Front panel USB header
Q Front panel USB header
R Front panel header
S Alternate front panel power LED header
T Serial port header
U Intel High Definition Audio Link header
V S/PDIF header
