Intel Braswell Series User Manual

9
JPCOM3/JPCOM4/JPCOM5/JPCOM6 (4-pin): COM3/4/5/6 Header Pin9 Function
Select
(2.54 pitch)
JPCOM3 → COM3 Header Pin9
JPCOM4 → COM4 Header Pin9
JPCOM5 → COM5 Header Pin9
JPCOM6 → COM6 Header Pin9
4-6 Closed:
RI= +12V.
1
3
5
3-4 Closed:
RI= +5V;
2-4 Closed:
RI=RS232;
4
6
2
6
5
3
1
4
2
5
3
1
6
4
2
JPLCD (4-pin): LVDS Panel VCC 3.3V/5V/12V Select
(2.54 pitch)
JPLCD → LVDS Panel VCC
1
3
5
4
6
2
6
5
3
1
4
2
5
3
1
6
4
2
2-4 Closed:
VCC=3.3V;
(Default);
3-4 Closed:
VCC= 5V
4-6 Closed:
VCC= 12V.
JPCOM3
JPCOM4
JPCOM5
JPCOM6
