英特尔台式机主板 D525MW 产品指南
连接到前面板音频接头连接器
12 中的 A 显示了前面板音频接头连接器的位置。前面板音频接头连接器可用于英特尔
高保真音频和 AC ‘97 音频
5 列出了英特尔高保真音频的引脚分配,而表 6 则列出了 AC ‘97 音频的引脚分配。
5. 前面板英特尔高保真音频接头连接器
引脚 信号名称 引脚 信号名称
1 [Port 1] Left channel
([端口 1]左声道)
2
Ground(接地)
3 [Port 1] Right channel
([端口 1 右声道)
4 PRESENCE# (Dongle present)
(有加密狗)
5 [Port 2] Right channel
([端口 2]右声道)
6 [Port 1] SENSE_RETURN
([端口 1SENSE_RETURN
7 SENSE_SEND (Jack detection)
(插孔检测)
8
Key(无引脚)
9 [Port 2] Left channel
([端口 2]左声道)
10 [Port 2] SENSE_RETURN
([端口 2SENSE_RETURN
6. 前面板 AC ’97 音频接头连接器
引脚 信号名称 引脚 信号名称
1
MIC(话筒)
2 AUD_GND
3 MIC_BIAS 4 AUD_GND
5 FP_OUT_R 6 FP_RETURN_R
7 AUD_5V 8
KEY(无引脚)
9 FP_OUT_L 10 FP_RETURN_L
连接到 S/PDIF 接头连接器
在连接到 S/PDIF 连接器上之前,请首先阅读并遵守第 23 “开始之前”中的注意事项。
12 中的 B(第 33 页)显示了 S/PDIF 接头连接器的位置。
7 列出了 S/PDIF 接头连接器的引脚分配。
7. S/PDIF 接头连接器
引脚 信号名称
1
Ground(接地)
2
S/PDIF outS/PDIF 输出)
3
Key(无引脚)
4
+5 VDC(直流 5 V
34
