Page #35 background imageLoading...
Page #35 background image
安装和更换台式机主板组件
连接到串行端口接头连接器
在连接到串行端口接头连接器上之前,请首先阅读并遵守第 23 页“开始之前”中的注意事项。
12 中的 C(第 33 页)显示了串行端口接头连接器的位置。
8 列出了串行端口接头连接器的引脚分配。
8. 串行端口接头连接器 (COM 1)
引脚 信号名称 引脚 信号名称
1 DCD (Data Carrier Detect)
(数据载体检测)
2 RXD# (Receive Data)
(接收数据)
3 TXD# (Transmit Data)
(发送数据)
4 DTR (Data Terminal Ready)
(数据终端就绪)
5
Ground(接地)
6 DSR (Data Set Ready)
(数据设置就绪)
7 RTS (Request To Send)
(请求发送)
8 CTS (Clear To Send)
(清除发送)
9
RI (Ring Indicator)(振铃指示灯)
10
Key(无引脚)
连接到前面板 USB 2.0 接头连接器
在连接到 USB 2.0 接头连接器上之前,请首先阅读并遵守第 23 “开始之前”中的注意事项。
12 中的 D G(第 33 页)显示了各 USB 2.0 接头连接器的位置。表 9 和表 10 列出了
这些接头连接器的引脚分配。
褐色 USB 接头连接器(图 12 中的 G)支持一个 USB 端口,而黑色 USB 接头连接器
(图 12 中的 D)则支持两个 USB 端口。按设计,此单个 USB 端口接头连接器支持快闪内存
驱动器,如英特尔 Z-U130 USB 固态驱动器(或兼容设备)。有关更详尽信息,请参阅第 32
“安装英特尔
®
Z-U130 USB 固态驱动器或兼容设备”。
9. 前面板 USB 接头连接器
引脚 信号名称 引脚 信号名称
1
+5 VDC(直流 +5 V
2
+5 VDC(直流 +5 V
3
D-
4
D-
5
D+
6
D+
7
Ground(接地)
8
Ground(接地)
9
KEY(无引脚)
10
No Connect(未连接)
10. 前面板 USB 接头连接器(支持英特尔 Z-U130 USB 固态驱动器或兼容设备)
引脚 信号名称 引脚 信号名称
1
+5 VDC(直流 +5 V
2
No Connect(未连接)
3
D-
4
No Connect(未连接)
5
D+
6
No Connect(未连接)
7
Ground(接地)
8
No Connect(未连接)
9
KEY(无引脚)
10
LED#
35
