安装和更换台式机主板组件
连接机箱风扇
13 显示了机箱风扇接头连接器的位置。请将机箱风扇电缆连接到此接头连接器上。
13. 机箱风扇接头连接器位置
37

Table of Contents

Other manuals for Intel D525MW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel D525MW and is the answer not in the manual?

Intel D525MW Specifications

General IconGeneral
ECCNo
Non-ECCYes
Memory channelsSingle-channel
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory4 GB
Supported memory clock speeds800, 1066 MHz
Product familyDesktop board
Product seriesIntel® Desktop Boards with Intel Atom® Processors
Processor socket-
Number of Parallel ATA connectors0
USB 2.0 ports quantity8
Parallel ports quantity1
Market segmentDesktop
Power source typeATX
Motherboard chipsetIntel® NM10 Express
Audio output channels5.1 channels
Motherboard chipset ID47610
Motherboard form factormini ITX
Motherboard chipset familyIntel
Compatible operating systemsWindows XP, Vista, 7
Parallel processing technology supportNot supported
Networking features10/100/1000
Audio channels6
Graphics outputVGA
Motherboard ARK ID48952
Discrete graphics card modelNone
Commodity Classification Automated Tracking System (CCATS)NA
StatusDiscontinued
Form factorMini-ITX
Last change63903513
Launch dateQ4'10
USB ports quantity7
Sustainability certificatesENERGY STAR
Supported RAID configurationN/A
Harmonized System (HS) code8471500150
