Page #52 background imageLoading...
Page #52 background image
英特尔台式机主板 D525MW 产品指南
BIOS 前面板电源 LED 指示灯闪烁代码
另外,BIOS 还通过闪烁前面板电源 LED 指示灯指示状态消息和错误消息,表明 POST(开机
自检)期间所发生的某些可恢复错误。表 16 列出了各种闪烁代码。
16. BIOS 前面板电源 LED 指示灯闪烁代码
类型 方式 说明
正在进行 BIOS 更新 更新开始时熄灭,然后亮起 0.5 秒,再后熄灭
0.5 秒。这一方式反复进行,直到 BIOS 更新
完成为止。
视频错误 亮起-熄灭(各 1.0 秒)两次,然后暂停(熄灭)
2.5 秒;这一整体方式反复进行(闪烁和暂停),
直到切断系统电源为止。
当未找到 VGA 选项 ROM 时。
内存错误 亮起-熄灭(各 1.0 秒)三次,然后暂停(熄灭)
2.5 秒;这一整体方式反复进行(闪烁和暂停),
直到切断系统电源为止。
热脱扣警告 每一声笛音都伴随以下的闪烁方式:亮起
0.25 秒,熄灭 0.25 秒,亮起 0.25 秒,熄灭
0.25 秒。这一闪烁方式共进行 16 次,随后系统
关机。
POST(开机自检)错误消息
再者,当 POST(开机自检)期间发生某些可恢复错误时,BIOS 还在视频显示器上显示错误消息。
17 列出了各种错误消息及其简要说明。
17. POST(开机自检)错误消息
错误消息 说明
CMOS 电量低 电池电量即将耗尽。
CMOS 校验和错误 CMOS 校验和不正确。CMOS 内存可能已损坏。请运行 Setup
(设置)程序以复位值。
内存容量减少 内存容量自上次启动后减少。如果未拆卸内存,那么内存可能
发生故障。
无可用启动设备 系统未找到启动设备。
52
