Desktop Board Features
11
Processor
CAUTION
Failure to use an ATX12V power supply, or not connecting the additional power supply lead to the
D845HV or D845WN boards may result in damage to the desktop board and/or power supply.
The boards support a single Intel Pentium 4 processor. Processors are not included with the board
and must be purchased separately.
The processor connects to the board through the mPGA 478-pin socket. The Intel Pentium 4
processor may be removed and replaced to accommodate supported higher speed processors.
The board supports the processors listed in Table 2.
Table 2. Processors Supported by the Desktop Board
Type
Designation
System Bus Frequency L2 Cache Size
Intel Pentium 4 processor
in an mPGA-478 package
1.4, 1.5, 1.6, 1.7, and
1.8 GHz
400 MHz 256 KB
For the latest information on processor support for the D845HV and D845WN boards, refer to the
Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop/
For instructions on installing or upgrading the processor, see Chapter 2 on page 21.
The D845HV and D845WN boards require an ATX12V compliant power supply to function
according to desktop board specifications. Both boards have two ATX12V compliant power
supply connectors that are needed to provide extra power to the Intel 845 chipset and Intel
Pentium 4 processor.
Items A and E in Figure 21 on page 70 show the two power connector locations.
Main Memory
✏
NOTE
To be fully compliant with all applicable Intel
®
SDRAM memory specifications, the board should
be populated with DIMMs that support the Serial Presence Detect (SPD) data structure. If your
memory modules do not support SPD, you will see a notification to this effect on the screen at
power up. The BIOS will attempt to configure the memory controller for normal operation.
The boards supports system memory as defined below:
• Up to three 168-pin SDRAM Dual Inline Memory Modules (DIMMs) with gold-plated
contacts
• PC133 SDRAM only
