Product Description
13
Table 3. Board Components Shown in Figure 1
Item/callout
from Figure 1
Description
A
Auxiliary fan connector (optional)
B
Speaker
C
PCI Express x1 bus add-in card connectors [2]
D
Audio codec
E
Front panel audio connector
F
Ethernet device
G
PCI Conventional bus add-in card connectors [2]
H
PCI Express x16 bus add-in card connector
I
Back panel connectors
J
+12V power connector (ATX12V)
K
Rear chassis fan connector
L
LGA775 processor socket
M
Intel
82945PL MCH
N
Processor fan connector
O
DIMM Channel A socket
P
DIMM Channel B socket
Q
SCSI LED connector (optional)
R
Legacy I/O controller
S
Power connector
T
Diskette drive connector
U
Parallel ATE IDE connector
V
Battery
W
Front chassis fan connector
X
BIOS Setup configuration jumper block
Y
Serial ATA connectors [4]
Z
Auxiliary front panel power LED connector
AA
Front panel connector
BB
Front panel USB connectors [2]
CC
Chassis intrusion connector
DD
Intel
82801G I/O Controller Hub (ICH7)
EE
SPI flash device
FF
PCI Conventional bus add-in card connectors [2]
