Intel Desktop Board D946GZAB Product Guide
12
Table 2. Desktop Board D946GZAB Components
Label Description
A HD Audio Link header
B PCI bus connector 2
C Front panel audio header
D PCI bus connector 1
E PCI Express x1 connector
F PCI Express x16 connector
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin )
I Rear chassis fan header (3-pin)
J Processor socket
K Processor fan header (4-pin)
L DIMM 0 Channel A socket
M DIMM 0, Channel B socket
N Main power connector (2 x 12 pin)
O Diskette drive connector
P IDE connector
Q Battery
R Front chassis fan header (3-pin)
S Chassis intrusion header
T Alternate front panel power LED header
U Front panel header
V Serial ATA connectors
W Hi-speed USB 2.0 headers
X Speaker
Y BIOS configuration jumper block
Related Links:
Go to the following links for more information about:
• Desktop Board D946GZAB
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://www.intel.com/go/FindCPU
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
To Next Page
