Intel D946GZAB - Desktop Board Motherboard - Jumper Settings for the BIOS Setup Program Modes

Installing and Replacing Desktop Board Components
51
The three-pin BIOS jumper block enables all board configurations to be done in the
BIOS Setup program.
Table 10 shows the jumper settings for the BIOS Setup
program modes.
Table 10. Jumper Settings for the BIOS Setup Program Modes
Jumper
Setting Mode Description
Normal (default) (1-2) The BIOS uses the current configuration and
passwords for booting.
Configure (2-3) After the Power-On Self-Test (POST) runs, the
BIOS displays the Maintenance Menu. Use this
menu to clear passwords.
Recovery (None) The BIOS recovers data in the event of a failed
BIOS update.
