Intel Desktop Board D946GZAB Product Guide
16
Related Links:
Go to the following link or pages for more information about:
• Audio drivers and utilities
http://support.intel.com/support/motherboards/desktop/
• Installing the front panel audio solution, page
43
• The location of audio connectors,
Figure 21 on page 46
Input/Output (I/O) Controller
The super I/O controller features the following:
• One serial port
• One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) support
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• PS/2-style mouse and keyboard interfaces
• Interface for one 1.2 MB or 1.44 MB diskette drive
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
LAN Subsystem
The LAN subsystem consists of the following:
• Intel
®
82562GX Platform LAN Connect (PLC) device for 10/100 Mb/s Ethernet LAN
connectivity
• RJ-45 connector with status indicator LEDs
LAN Subsystem Software
For LAN software and drivers, refer to the D946GZAB link on Intel’s World Wide Web
site at:
http://support.intel.com/support/motherboards/desktop
