Intel Denverton Series User Manual

5
Jumper
P/N Function Description
JBAT Pin (1-2): Clear CMOS
Pin (3-4): Clear RTC
Pin (5-6): Flash Override
Pin (7-8): ME Recovery
8-Pin Block
COPEN Case Open Message Display Select 2-Pin Block
JP1 Power Switch Selection 3-Pin Block
JP3 COM1 Header Pin9 Function Select 4-Pin Block
JP4 COM2 Header Pin9 Function Select 4-Pin Block
Connectors
Connector
Name
ATXPWR Main Power Connector
ATX12V CPU Power Connector
CPUFAN CPUFAN Connector
SYSFAN SYSFAN Connector
SATA1/2/3/4 SATAIII Port Connector
USB3 USB 3.0 Port Connector
UL1/UL2 Top: RJ-45 LAN Port Connector
Bottom: USB 3.0 Port Connector
SFP1/ SFP2 Small Form-factor Pluggable Connector
MPE Full-size Mini-PCIE Slot
M2 M.2 Socket 3 Slot
