Intel Denverton Series User Manual

4
Internal Diagram-Back Side:
* JP2: JTAG option, for in-house test purpose only.
SATAIII Ports
GPIO Port
Header
VGA Port
Header
Intel
CPU
DDR4
U-DIMM/R-DIMM
Slot x 4
ATX 12V
Power Connector
ATX Main
Power Connector
Front Panel
Header
SYSFAN
Connector
USB 3.0 Port
RJ-45 LAN Ports
Over USB 3.0 Ports
SFP+ Ports
C
OM2
Serial Port
Header
USB 2.0 Port
Header
Full
-
size
Mini-
PCIE Slot
(MPE)
CPUFAN
Connector
PCIE x8 Slot
C
OM1
Serial Port
Header
M.2 M Key
Socket 3
Slot
JP3
JP4
COPEN
JBAT
*JP2
JP1
