Intel DH61AG Product Guide

Intel Desktop Board DH61AG Product Guide
10
Table 1. Feature Summary (continued)
Audio
• 10-channel (8 + 2) Intel
®
High Definition Audio (Intel
®
HD Audio)
using a Realtek* ALC892 audio codec supporting:
― Digital/analog stereo line-out (2-in-1 digital/analog backpanel
jack)
― In-chassis stereo speakers support (internal connector)
― AV-compliant 7.1 surround support (analog line-level via an
internal header)
― Secondary S/PDIF digital audio output (internal header)
― DMIC digital microphone input (internal header)
― Analog line-in (backpanel jack)
― Front panel HD Audio/AC’97 headphones/mic support (internal
header)
• 8-channel (7.1) Intel HD Audio via the HDMI interface
Expansion
Capabilities
• One PCI Express 2.0 x4 add-in card connector
• One PCI Express Full-/Half-Mini Card slot (including mini-SATA
(mSATA) support)
• One PCI Express Half-Mini Card slot
Peripheral
Interfaces
USB Support:
• Two USB 3.0 ports implemented with stacked back panel
connectors (blue)
• Seven exposed USB 2.0 ports including:
― Two high-current/fast-charging ports implemented with
stacked back panel connectors (yellow)
― Five front panel ports implemented with two dual-port internal
headers and one single-port internal header
Serial ATA Support:
• Two internal SATA 3.0 Gb/s ports
• One internal mSATA 3.0 Gb/s port (PCI Express Full-Mini Card slot)
• One external SATA (eSATA) 3.0 Gb/s port (red)
Legacy I/O
Legacy I/O Controller (Nuvoton* W83677HG-I) that provides
Consumer Infrared (CIR) and hardware management support
LAN Support Intel
®
82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
including an RJ-45 back panel connector with integrated status LEDs
BIOS
• Intel
®
BIOS resident in a Serial Peripheral Interface (SPI) Flash
device
• Support for Advanced Configuration and Power Interface (ACPI),
Plug and Play, and System Management BIOS (SMBIOS)
• Unified Extensible Firmware Interface (UEFI) to support hard disk
drives larger than 2 TB
Instantly Available
PC Technology
• Suspend to RAM support
• Wake on PCI Express, LAN, front panel, CIR, and USB ports
continued

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
