Intel Desktop Board DH61AG Product Guide
22
6. Carefully lower the socket lever (Figure 9, A) while making sure that the front edge
of the load plate slides under the shoulder screw cap as the lever is lowered. Latch
the socket lever under the load plate tab (Figure 9, C, D). The socket cover
(Figure 9, B) will pop off as shown.
Figure 9. Secure the Load Plate in Place
7. Pick up the socket cover and remove it from the desktop board.
NOTE
Do not discard the socket cover; save it for possible future use. Always replace
the socket cover if you remove the processor from the socket.
