Front Panel Dual-Port USB 2.0 Headers
Figure 16, G shows the location of the front panel dual-port USB 2.0 headers and
Table 10 shows their pin assignme
nts and signal names.
Table 10. Front Panel Dual-Port USB 2.0 Headers Signal Names
Pin Signal Name Pin Signal Name
1 Power (+5 V) 2 Power (+5 V)
3 D- 4 D-
5 D+ 6 D+
7 Ground 8 Ground
9 Key 10 No Connection
NOTE
Computer systems that have an unshielded cable attached to a USB port might not
meet FCC Class B requirements, even if no device or a low-speed USB device is
attached to the cable. Use a shielded cable that meets the requirements for a
full-speed USB device.
S/PDIF / DMIC Header
Figure 16, H shows the location of the S/PDIF / DMIC output header. Table 11 shows
the pin assignments and signal names for the S/PDIF / DMIC output header.
Table 11. S/PDIF / DMIC Header Signal Names
Pin Description
1 3.3 V
2 DMIC_DATA
3 Ground
4 SPDIF_OUT/DMIC_CLK
5 Key (no pin)
6 5 V
