Intel DH61BF User Manual

Product Description
23
1.11 LAN Subsystem
The LAN subsystem consists of the following:
• Realtek RTL8111E Gigabit Ethernet Controller (10/100/1000 Mb/s)
• Intel H61 Express Chipset
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface between the PCH and the LAN controller
• Power management
 ACPI technology support
 LAN wake capabilities
• LAN subsystem software
For information about
Refer to
LAN software and drivers http://downloadcenter.intel.com
1.11.1 Realtek RTL8111E Gigabit Ethernet Controller
The Realtek RTL811E Gigabit Ethernet Controller supports the following features:
• 10/100/1000 BASE-T IEEE 802.3 compliant
• Energy Efficient Ethernet (EEE) IEEE802.3az support (Low Power Idle [LPI] mode)
• Dual interconnect between the Integrated LAN Controller and the Physical Layer
(PHY):
 PCI Express-based interface for active state operation (S0) state
 SMBUS for host and management traffic (Sx low power state)
• Compliant to IEEE 802.3x flow control support
• 802.1p and 802.1q
• TCP, IP, and UDP checksum offload (for IPv4 and IPv6)
• Full device driver compatibility
1.11.2 LAN Subsystem Software
LAN software and drivers are available from Intel’s World Wide Web site.
For information about Refer to
Obtaining LAN software and drivers Section 1.2, page 16

Intel DH61BF Specifications

General

Form Factor	microATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	4 x USB 2.0
SATA Ports	4
Video Outputs	VGA, DVI-D
BIOS	UEFI
