Intel Desktop Board DH61BF Technical Product Specification
40
Table 10. Component-side Connectors and Headers Shown in Figure 9
Item/callout
from Figure 1 Description
A PCI Express 2.0 x1 bus add-in card connector
B PCI Express 2.0 x1 bus add-in card connector
C PCI Express 3.0 x16 bus add-in card connector
D Rear chassis fan header
E 12 V processor core voltage connector (2 X 2)
F Processor fan header
G Main power connector (2 x 12)
H SATA connectors
I Front panel header
J Front panel USB 2.0 header
K Front panel USB 2.0 header
L Serial port header
M Front panel audio header

Intel DH61BF Specifications

General

Form Factor	microATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	4 x USB 2.0
SATA Ports	4
Video Outputs	VGA, DVI-D
BIOS	UEFI
