Intel Desktop Board DH77EB Technical Product Specification
18
1.3.1.2 PCI Express x16 Graphics
3
rd
generation Intel Core processor family processors support PCI Express 3.0, 2.x,
and 1.x and 2
nd
generation Intel Core processor family processors support PCI
Express 2.x and 1.x:
• PCI Express 3.0 with a raw bit rate of 8.0 GT/s results in an effective bandwidth of
1 GB/s each direction per lane. The maximum theoretical bandwidth of the x16
interface is 16 GB/s in each direction, simultaneously, for a total bandwidth of
32 GB/s.
• PCI Express 2.x with a raw bit rate of 5.0 GT/s results in an effective bandwidth of
500 MB/s each direction per lane. The maximum theoretical bandwidth of the x16
interface is 8 GB/s in each direction, simultaneously, for a total bandwidth of
16 GB/s.
• PCI Express 1.x with a raw bit rate of 2.5 GT/s results in an effective bandwidth of
250 MB/s each direction per lane. The maximum theoretical bandwidth of the x16
interface is 4 GB/s in each direction, simultaneously, for a total bandwidth of
8 GB/s.
For information about Refer to
PCI Express technology http://www.pcisig.com

Intel DH77EB Specifications

General

Form Factor	ATX
Chipset	Intel H77
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16 Slots	1
SATA 6Gb/s Ports	2
SATA 3Gb/s Ports	3
USB 3.0 Ports	4
USB 2.0 Ports	8
Audio	Realtek ALC892
LAN	Intel 82579V
Video Outputs	HDMI, DVI
PCI Express x1 Slots	3 x PCIe 2.0 x1
