Technical Reference

2.2.2.1 Signal Tables for the Connectors and Headers

Table 15. Front Panel Audio Header for Intel HD Audio

Pin Signal Name Pin Signal Name

1 [Port 1] Left channel 2 Ground

3 [Port 1] Right channel 4 PRESENCE# (Dongle present)

5 [Port 2] Right channel 6 [Port 1] SENSE_RETURN

7 SENSE_SEND (Jack detection) 8 Key (no pin)

9 [Port 2] Left channel 10 [Port 2] SENSE_RETURN

Table 16. Front Panel Audio Header for AC ’97 Audio

Pin Signal Name Pin Signal Name

1 MIC 2 AUD_GND

3 MIC_BIAS 4 AUD_GND

5 FP_OUT_R 6 FP_RETURN_R

7 AUD_5V 8 KEY (no pin)

9 FP_OUT_L 10 FP_RETURN_L

Table 17. Front Panel USB 2.0 Headers

Pin Signal Name Pin Signal Name

1 +5 V DC 2 +5 V DC

3 D- 4 D-

5 D+ 6 D+

7 Ground 8 Ground

9 KEY (no pin) 10 No Connect
