Intel Desktop Board DH77EB Technical Product Specification
46
Table 14 lists the component-side connectors and headers identified in Figure 10.
Table 14. Component-side Connectors and Headers Shown in Figure 10
Item/callout f
rom Figure 10 Description
A Front panel audio header
B PCI Express x1 add-in card connector
C PCI Express x1 add-in card connector
D PCI Express x16 add-in card connector
E PCI Express x1 add-in card connector
F Parallel port header
G Processor core power connector (2 x 2)
H Processor fan header
I LPC Debug connector
J Front fan header
K Chassis intrusion header
L Consumer IR receiver (input) header
M Consumer IR emitter (output) header
N Main power connector (2 x 12)
O Front panel USB 3.0 connector
P S/PDIF out header
Q PCI Express Full-/Half-Mini Card slot
R Alternate front panel power/sleep LED header
S Front panel header
T SATA 6.0 Gb/s connector (multiplexed with an mSATA port, routed to the PCI
Express Full-/Half-Mini Card slot) (gray)
U SATA 3.0 Gb/s connector through the PCH (black)
V SATA 6.0 Gb/s connector through the PCH (blue)
W Front panel USB 2.0 header
X Front panel USB 2.0 header
Y Front panel USB 2.0 header
Z Serial port header
AA Rear chassis fan header

Intel DH77EB Specifications

General

Form Factor	ATX
Chipset	Intel H77
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16 Slots	1
SATA 6Gb/s Ports	2
SATA 3Gb/s Ports	3
USB 3.0 Ports	4
USB 2.0 Ports	8
Audio	Realtek ALC892
LAN	Intel 82579V
Video Outputs	HDMI, DVI
PCI Express x1 Slots	3 x PCIe 2.0 x1
