Technical Reference

Table 26. PCI Express Full-/Half-Mini Card Connector

Pin Signal Name Additional Signal Name

1 WAKE#

2 +3.3 V aux

3 Reserved

4 GND

5 Reserved

6 1.5 V

7 CLKREQ#

8 Reserved

9 GND

10 Reserved

11 REFCLK-

12 Reserved

13 REFCLK+

14 Reserved

15 GND

16 Reserved

17 Reserved

18 GND

19 Reserved

20 Reserved

21 GND

22 PERST#

23 PERn0

24 +3.3 V aux

25 PERp0

26 GND

27 GND

28 +1.5 V

29 GND

30 SMB_CLK

31 PETn0

32 SMB_DATA

33 PETp0

34 GND

35 GND

36 USB_D-

37 GND (mSATA) GND

38 USB_D+

continued

Questions and Answers:

Need help?

Do you have a question about the Intel DH77EB and is the answer not in the manual?

Intel DH77EB Specifications

General

Form Factor	ATX
Chipset	Intel H77
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16 Slots	1
SATA 6Gb/s Ports	2
SATA 3Gb/s Ports	3
USB 3.0 Ports	4
USB 2.0 Ports	8
Audio	Realtek ALC892
LAN	Intel 82579V
Video Outputs	HDMI, DVI
PCI Express x1 Slots	3 x PCIe 2.0 x1
