Error Messages and Beep Codes
77
4.5 Port 80h Power On Self Test (POST) Codes
During the POST, the BIOS generates diagnostic progress codes (POST codes) to I/O
port 80h. If the POST fails, execution stops and the last POST code generated is left
at port 80h. This code is useful for determining the point where an error occurred.
Displaying the POST codes requires a POST card that can interface with the Low Pin
Count (LPC) Debug connector. The POST card can decode the port and display the
contents on a medium such as a seven-segment display. Refer to the location of the
LPC Debug connector in Figure 1.
The following tables provide information about the POST codes generated by the BIOS:
• Table 48 lists the Port 80h POST code ranges
• Table 49 lists the Port 80h POST codes themselves
• Table 50 lists the Port 80h POST sequence
NOTE
In the tables listed above, all POST codes and range values are listed in hexadecimal.
Table 48. Port 80h POST Code Ranges
Range Subsystem
0x00 – 0x05 Entering SX states S0 to S5.
0x10, 0x20, 0x30,
0x40, 0x50
Resuming from SX states. 0x10 – S1, 0x20 – S2, 0x30 – S3, etc.
0x08 – 0x0F Security (SEC) phase
0x11 – 0x1F PEI phase pre MRC execution
0x21 – 0x29 MRC Memory detection
0x2A – 0x2F PEI phase post MRC execution
0x31 – 0x35 Recovery
0x36 – 0x3F Platform DXE driver
0x41 – 0x4F CPU Initialization (PEI, DXE, SMM)
0x50 – 0x5F I/O Buses: PCI, USB, ISA, ATA etc. 0x5F is an unrecoverable error. Start with PCI.
0x60 – 0x6F BDS
0x70 – 0x7F Output Devices: All output consoles.
0x80 – 0x8F For future use
0x90 – 0x9F Input devices: Keyboard/Mouse.
0xA0 – 0xAF For future use
0xB0 – 0xBF Boot Devices: Includes fixed media and removable media. Not that critical since
consoles should be up at this point.
0xC0 – 0xCF For future use
0xD0 – 0xDF For future use
0xF0 – 0xFF
