Intel Desktop Board DH77EB Technical Product Specification

Table 35. BIOS Setup Configuration Jumper Settings

Function/Mode Jumper Setting Configuration

Normal

1-2

The BIOS uses current configuration information and passwords

for booting.

Configure

2-3

After the POST runs, Setup runs automatically. The

maintenance menu is displayed.

Note that this Configure mode is the only way to clear the

BIOS/CMOS settings. Press F9 (restore defaults) while in

Configure mode to restore the BIOS/CMOS settings to their

default values.

Recovery

None

The BIOS attempts to recover the BIOS configuration. A

recovery CD or flash drive is required.
