Intel DH77EB User Manual

iii
Board Identification Information
Basic Desktop Board DH77EB Identification Information
AA Revision BIOS Revision Notes
G39073-303
EBH7710H.86A.0041
1,2
G39073-304
EBH7710H.86A.0053
1,2
G39073-400
EBH7710H.86A.0053
1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The H77 processor used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
Intel H77 Express Chipset C1 SLJ88
Errata
Current characterized errata, if any, are documented in a separate Specification
Update. See http://developer.intel.com/products/desktop/motherboard/index.htm
for the latest documentation.

Intel DH77EB Specifications

General

Form Factor	ATX
Chipset	Intel H77
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16 Slots	1
SATA 6Gb/s Ports	2
SATA 3Gb/s Ports	3
USB 3.0 Ports	4
USB 2.0 Ports	8
Audio	Realtek ALC892
LAN	Intel 82579V
Video Outputs	HDMI, DVI
PCI Express x1 Slots	3 x PCIe 2.0 x1
