Intel Desktop Board DQ57TML Technical Product Specification
12
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1
Descript
ion
A Conventional PCI bus add-in card connector
B PCI Express x1 add-in card connector
C Battery
D PCI Express x1 add-in card connector
E Piezoelectric speaker
F PCI Express x16 add-in card connector
G Back panel connectors
H 12 V internal power connector (ATX12V)
I Rear chassis fan header
J LGA1156 processor socket
K Processor fan header
L DIMM Channel A sockets (2)
M DIMM Channel B sockets (2)
N Front chassis fan header
O Chassis intrusion header
P Diskette drive connector
Q Main power connector (2 x 12)
R SATA connectors
S Alternate front panel power LED header
T Front panel header
U Standby power LED
V Front panel USB header (with Intel Z-U130 USB Solid-State Drive, or compatible
device, support)
W Intel ME “M” state LED
X Intel Q57 Express Chipset
Y Front panel USB headers (3)
Z BIOS setup configuration jumper block
AA Intel
®
Management Engine BIOS Extension (Intel
®
MEBx) Reset header
BB Intel Remote PC Assist header
CC Serial port header
DD S/PDIF header
EE Front panel audio header
FF Internal mono speaker header
