Intel DQ57TM - Chassis Intrusion Header; Processor (4-Pin) Fan Header; Front and Rear Chassis Fan Headers; Intel Remote PC Assist Technology Header

Intel Desktop Board DQ57TML Technical Product Specification
50
Table 21. Chassis Intrusion Header
Pin Signal Name
1 Intruder#
2 Ground
Table 22. Processor (4-Pin) Fan Header
Pin Signal Name
1 Ground
2 +12 V
3 FAN_TACH
4 FAN_CONTROL
Table 23. Front and Rear Chassis Fan Headers
Pin 4-Wire Support Pin 3-Wire Support
1 Ground 3 Ground
2 +12 V 2 FAN_POWER
3 FAN_TACH 1 FAN_TACH
4 FAN_CONTROL N/A N/A
Table 24. Intel Remote PC Assist Technology Header
Pin Signal Name
1 RPAT#
2 Ground
