Intel Desktop Board DQ57TML Technical Product Specification
46
Table 11. Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11 Descript
ion
A PCI Conventional bus add-in card connector
B PCI Express x1 bus add-in card connector
C PCI Express x1 bus add-in card connector
D PCI Express x16 bus add-in card connector
E 12 V internal power connector (ATX12V)
F Rear chassis fan header
G Processor fan header
H Front chassis fan header
I Chassis intrusion header
J Diskette drive connector
K Main power connector (2 x 12)
L SATA connectors
M Alternate front panel power LED header
N Front panel header
O Front panel USB header (with Intel Z-U130 USB Solid-State Drive, or compatible
device, support)
P Front panel USB headers (3)
Q Intel Remote PC Assist header
R Serial port header
S S/PDIF header
T Front panel audio header
U Internal mono speaker header

Intel DQ57TM Specifications

General

Form Factor	Micro ATX
Chipset	Intel Q57
Socket	LGA 1156
Memory Type	DDR3
Memory Slots	4
Maximum Memory	16 GB
PCI Express x16 Slots	1
PCI Express x1 Slots	2
PCI Slots	1
SATA Ports	6
eSATA	1
USB Ports	12
Ethernet	Gigabit Ethernet
RAID Support	RAID 0, 1, 5, 10
Video Output	DVI, VGA
Audio	Realtek ALC888S
