Intel Desktop Board DQ965GF Product Guide
12
Table 2. Desktop Board DQ965GF Components
Label Description
A HD Audio Link header
B PCI bus connector 2
C Front panel audio header
D PCI bus connector 1
E PCI Express x1 connector
F PCI Express x16 connector
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin )
I Rear chassis fan header (3-pin)
J Processor socket
K Processor fan header (4-pin)
L Serial port header
M Main power connector (2 x 12 pin)
N Diskette drive connector
O DIMM 0, Channel A and B sockets
P DIMM 1, Channel A and B sockets
Q Battery
R Front chassis fan header (3-pin)
S Chassis intrusion header
T BIOS configuration jumper block
U Alternate front panel power LED header
V Front panel header
W Serial ATA connectors
X Hi-speed USB 2.0 headers
Y Speaker
Z IDE connector
AA IEEE 1394a header
Related Links:
Go to the following links for more information about:
• Desktop Board DQ965GF
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
