Installing and Replacing Desktop Board Components
35
Removing the Processor
For instructions on how to remove the processor fan heat sink and processor, refer to
the processor installation manual or the Intel World Wide Web site at:
2Integration of the Boxed Intel
®
Pentium
®
4 Processor in the 775-Land Package
Installing and Removing Memory
CAUTION
When connected to AC power, the memory slots on the board will be powered and in
use. A red LED, located near the memory slots, will be lit if the memory slots are
powered.
Installing or removing memory from the board while the memory slots are powered
may result in damage to both memory and board.
Before installing or removing memory, disconnect the system from AC power and wait
for the LED to go off before proceeding.
NOTE
To be fully compliant with all applicable Intel
®
SDRAM memory specifications, the
board requires DIMMs that support the Serial Presence Detect (SPD) data structure.
You can access the PC Serial Presence Detect Specification at:
http://www.intel.com/technology/memory/ddr/specs/dda18c32_64_128x72ag_a.pdf
Desktop Board DQ965GF has four 240-pin DDR2 DIMM sockets arranged as DIMM 0
and DIMM 1 in both Channel A and Channel B.
Guidelines for Dual Channel Memory Configuration
Before installing DIMMs, read and follow these guidelines for dual channel
configuration.
NOTE
The Intel Management Engine in the chipset requires memory to be populated in
Channel A, DIMM 0 in order for it to enable Intel Quiet System Technology and
Intel Active Management Technology.
