Intel Desktop Board DX79TO Technical Product Specification
32
1.12.1.2 Wake-up Devices and Events
Table 9 lists the devices or specific events that can wake the computer from specific
states.
Table 9. Wake-up Devices and Events
Devices/events can wake up the computer… …from this state …from this global state
Power switch S3, S4, S5
(
Note 1)
G1, G2, G3
RTC alarm S3, S4, S5
(Note 1)
G1, G2
(Note 3)
LAN S3, S4, S5
(Note 1)
G1, G2
(Note 3)
USB S3 G1
PME# signal S3, S4, S5
(Note 1)
G1, G2
(Note 3)
WAKE# S3, S4, S5
(Note 1)
G1, G2
(Note 3)
Consumer IR S3, S4, S5
(Note 2)
Notes:
1. S4 implies operating system support only.
2. Wake from S4 and S5 is recommended by Microsoft.
3. Wake from device/event not supported immediately upon return from AC loss.
NOTE
The use of these wake-up events from an ACPI state requires an operating system that
provides full ACPI support. In addition, software, drivers, and peripherals must fully
support ACPI wake events.

Intel DX79TO Specifications

General

Form Factor	ATX
Chipset	Intel X79
Socket	LGA 2011
Memory Type	DDR3
Max Memory	64GB
PCIe 2.0 x1 Slots	2
PCI Slots	1
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 3.0 Ports	2
LAN	Intel 82579V
Memory Slots	8
