55
Console Command Reference
CHAPTER 3
SYS_console> get-lt-filter 00aa00a5898b
12 00-AA-00-A5-89-8B LOCK_OFF SELF_OFF --- VIRTUAL LAN -----
SRC PORT to : MGMT P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12
================================================================
1 - - - - - + - - - - - - -
2 - - - - - + - - - - - - -
3 - - - - - + - - - - - - -
4 - - - - - + - - - - - - -
5 - - - - - - - - - - - - -
6 - - - - - + - - - - - - -
7 - - - - - + - - - - - - -
8 - - - - - + - - - - - - -
9 - - - - - + - - - - - - -
10 - - - - - + - - - - - - -
11 - - - - - + - - - - - - -
12 - - - - - + - - - - - - -
get-lt-filter
get-lt-filter <mac_address>
Displays the custom filter for the specified MAC address. See the
previous example.
add-cf-entry
add-cf-entry {lock-on|lock-off|perm} <mac_address> <sport> <dport>
Adds a custom filter entry for the specified MAC address. lock-on
indicates the entry won’t be aged out, but will be lost when the switch
is reset.
lock-off indicates the entry can be aged out normally. perm
indicates the entry is written to NVRAM and remains after a reset.
sport is a hexadecimal representation of incoming ports, and dport is
a hexadecimal bitmask representation of outgoing ports.
Packets arriving at the switch with the destination MAC address from
any port specified in
sport are transmitted to all ports specified in
dport.
SYS_console> add-cf-entry perm 00-AA-00-11-11-11 C C0
Add CF LT entry OK
CF Entry Update in NVRAM OK
This custom filter sends packets with destination MAC address
00-AA-00-11-11-11 from port 3 or 4 (hexadecimal C) to ports 6 and 7
(hexadecimal C0).
