57
Console Command Reference
CHAPTER 3
get-con-matrix
Displays the current connectivity matrix for the switch. The first
column is the source port. The other columns are destinations where
frames from a given source port can be forwarded. Unlearned
addresses (addresses that aren’t in the switching database) are
forwarded to all ports marked with a + in the source port’s row.
Learned addresses are forwarded to their destinations only if the
destination is marked with a + in the source port’s row. Ports don’t
need to be forwarded to themselves.
SYS_console> get-con-matrix
VLAN CONNECTIVITY MATRIX
==========================
SRC PORT to : P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12
================================================================
1 - + + + + + + + - - - -
2 + - + + + + + + - - - -
3 + + - + + + + + - - - -
4 + + + - + + + + - - - -
5 + + + + - + + + - - - -
6 + + + + + - + + - - - -
7 + + + + + + - + - - - -
8 + + + + + + + - - - - -
9 - - - - - - - - - - - -
10 - - - - - - - - - - - -
11 - - - - - - - - - - - -
12 - - - - - - - - - - - -
get-vbc-matrix
Displays the current broadcast domain matrix for the switch. See the
get-con-matrix command above for a description of the resulting
table. Here, only the broadcast address is affected.
SYS_console> get-vbc-matrix
VBC CONNECTIVITY MATRIX
==========================
SRC PORT to : P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12
===============================================================
1 - + + + + + + + - - - -
2 + - + + + + + + - - - -
3 + + - + + + + + - - - -
4 + + + - + + + + - - - -
5 + + + + - + + + - - - -
6 + + + + + - + + - - - -
7 + + + + + + - + - - - -
8 + + + + + + + - - - - -
9 - - - - - - - - - - - -
10 - - - - - - - - - - - -
11 - - - - - - - - - - - -
12 - - - - - - - - - - - -
