Intel Express 10 User Manual

76
Appendix A Intel Express 10/100 Fast Ethernet Switch
Ports 1-8
Type: 10BASE-T/100BASE-TX (auto detecting),
twisted-pair Ethernet (TPE)
Duplex mode: Half
Flow control: On
Ports 9-12
Not installed (see Accessories on next page)
Console Manager
Communications parameters: 9600 baud, 8-N-1
Login name: None
Password: None
Prompt:
SYS_console>
Spanning tree
Spanning tree: Enabled
Bridge priority: 32768 0-65535
Bridge max. age: 20 6.0-40.0 sec.
Bridge hello time: 2 1.0-10.0 sec.
Bridge forward delay: 15 4.0-30.0 sec.
Port priority: 128 0-255
Path cost: 100 (1000/LAN speed in Mbps). If a port is
linked at 100 Mbps, the path cost is 10.
