Intel Desktop Board DH61CR Technical Product Specification
44
Table 10. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Description
A Conventional PCI bus add-in card connector
B PCI Express x1 add-in card connector
C Chassis intrusion header
D S/PDIF header
E PCI Express x1 add-in card connector
F PCI Express x16 bus add-in card connector
G 12 V internal power connector (ATX12V)
H Rear chassis fan header
I Processor fan header
J Front chassis fan header
K LPC Debug header
L TPM header
M Main power connector (2 x 12)
N SATA connectors
O Front panel header
P Alternate front panel power LED header
Q Intel MEBX Reset header
R Serial port header
S Front panel USB 2.0 header
T Front panel USB 2.0 header
U Front panel USB 2.0 header
V Internal mono speaker header
W Front panel audio header
