1-2 Specification
Spec Description
Design
z Micro ATX form factor; PCB size: 22.5*17.1cm
Chipset
z Intel G41 Memory Controller Hub (MCH) Chipset
z Intel 82801GB I/O Controller Hub (ICH7) Chipset
CPU Socket
(LGA775 )
z Supports the innovative 65nm and 90nm Intel
®
Celeron
®
400, Intel
®
Celeron
®
Dual Core, Pentium
®
Dual Core Processor, Intel
®
Core 2
Quad, Intel
®
Core 2 Duo
®
(Code Name: Conroe) Processor with
Intel
®
Hyper-Threading Technology and fully supports the future
45nm processors.
z Suggest the power of the CPU should below 65W
z Support FSB Frequency 1333 / 1066 / 800/533 MHz
Memory Socket
z 240-pin DDRIII RAM module socket x 2
z Supports two DDRIII 800 /DDRIII1066MHz RAM Module expandable
to 8GB
z Support dual-channel function
Expansion Slots
z PCI-Express x16 slot 1pcs.
z 32-bit PCI slot 1pcs
Integrate IDE and
Serial ATA2
z One PCI IDE controller that supports PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100 functions that deliver the
data transfer rate up to 100 MB/s; two Serial ATA2 ports each
provides 3.0 Gb /sec data transfer rate.
Integrated VGA
z Integrated Graphic Media Accelerator 4500
LAN
z Integrated PCI-E 10/100 LAN chip
z Support Fast Ethernet LAN function of providing 10Mb / 100Mb
data transfer rate
HD Audio
z Realtek ALC662 Azalia 6-channel Audio Codec integrated
z Audio driver and utility included
BIOS
z AMI 8MB DIP Flash ROM
Multi I/O
z PS/2 keyboard and PS/2 mouse connectors
z Serial port x1
z D-Sub 15-pin VGA Conn.
z USB 2.0 connector x 4, headers x1
z RJ-45 LAN connector x1
z Audio connector x1 (Line-in, Line-out, MIC)
z HDMI-SPDIF header x1
z SATA Connector x2
1-3 Item Checklist
5
Intel G41 Platform Processor Chipset based motherboard
5
DVD for motherboard utilities
5
SATA cable
5
User’s manual
5
Back panel
