1-4 Layout Diagram
ATX 12V Power
Connector
Front Panel
Header
ATX Power
Connector
CPU Socket mPGA775
Intel 82801GB
ICH Chipset
Power Led &
Speaker Header
DDRIII
DIMMx2
ALC662
HD Audio Codec
32-bit PCI Slot
Serial Port
K
B／MS Power ON
Jumper (JP1)
USB Ports
SYSFAN1
Front Panel
Audio Heade
r
Megabit LAN Chip
IDE Connector
Serial-ATA2
Connector (SATA1, 2)
CPU FAN
VGA Port
RJ-45 Ove
r
USB Ports
PCI Express x16 Slot
Intel G41Express
Chipset
USB Power ON Jumper (JP2)
PS2 KB/Mouse
Port
USB Header
HDMI-SPDIF Header
6-CH
Audio Connector
RJ45 LAN
PS/2 Mouse Port
PS/2 Keyboard Port
Line-IN
Line-OUT
MIC-IN
USB Ports
Serial Port
VGA Port

Intel G41 Express Chipset Specifications

General

Brand	Intel
Model	G41 Express Chipset
Category	Motherboard
Language	English
